East Adams Rural Hospital

East Adams Rural Hospital

DESCRIPTION: The electrical design consists of integrating two (2) projects, spread across several different contracting methods to address multiple code issues faced by the hospital.

The first project was an ESCO project designed to replace the HVAC and lighting systems, and also included replacement of the existing emergency generator and upgrading the existing NEC 517 emergency power systems. The first project was financed through State DES funding sources.

The second project was a design/bid/build project designed through a local architect for the general building renovation and addition, financed through a bond issue.

LOCATION: Ritzville, Washington
CLIENT: East Adams Rural Hospital
DELIVERY METHOD: Design-Build (DB) and Design-Bid-Build (DBB)
DESIGN-BUILD CONTRACTOR: Apollo Solutions Group – Spokane, Washington
DESIGN-BID-BUILD CONTRACTOR: Leone and Keeble – Spokane, Washington
ARCHITECT: NAC|Architecture – Spokane, Washington
SERVICES PROVIDED: Electrical System Design

Under Construction

LOCATION: Woodland, California

FACILITY SIZE: 49,000 Square Feet 90 Beds

CLIENT: Yolo County

DELIVERY METHOD: Design-Bid-Build (DBB)

ARCHITECT: Lionakis Sacramento, California

SERVICES PROVIDED: Security Electronics System Design

DESCRIPTION: This expansion and retrofit project included the addition of an 11,000 SF multipurpose building on the existing 4-acre site. The new free-standing facility includes a full-size basketball court, family visiting rooms, and two large multipurpose rooms for additional programs. The new facility will include a wireless duress system, digital intercom/paging, an IP CCTV system, and controlled doors from the existing central control location in the Juvenile facility. In the existing 38,000 square foot, 90-bed Juvenile facility, existing intercom/paging devices, and door control systems were updated and integrated into a new single control system that allows a control officer to monitor both facilities. A new IP based CCTV system and local storage was provided that replaced all existing cameras in the Juvenile Hall. Design documents are being provided for the following systems:

  • Cell and movement door control systems.
  • CCTV system.
  • Digital audio systems.
  • Personal Duress Alarm systems.
  • Network infrastructure.
  • UPS Systems.

California State Prison, Solano

California State Prison, Solano

DESCRIPTION: The Project is located at the California State Prison, Solano (SOL), an adult male prison with custody Level II and III inmates, in the City of Vacaville, California. The purpose of the health care facility improvement project at SOL is to remedy deficiencies in the health care components established by the California Correctional Health Care Services (CCHCS) program for Intermediate institutions. SOL has deficiencies in medication distribution, primary care, specialty care, and health records. The Project includes three sub-projects including the construction of new buildings, renovation of existing buildings, and ancillary site improvements to inmate movement including pedestrian sallyports . The following sub projects are intended to remedy the above deficiencies for this campus:

  • Sub-Project #1- New Complex Facility Clinic.
  • Sub-Project #2- Central Health Services (CHS) Renovation.
  • Sub-Project #4- New Medication Distribution Rooms.

LOCATION: Vacaville, California
PROJECT SIZE: 25,339 Square Feet
CLIENT: California Department of Corrections and Rehabilitation
DELIVERY METHOD: Design-Bid-Build (DBB)
ARCHITECT:
Perkins Eastman
Marina Del Rey, California
CGL Companies
Sacramento, California
SERVICES PROVIDED: Security Electronics System Design

California Medical Facility Solano

California Medical Facility Solano

LOCATION: Vacaville, California
PROJECT SIZE: 27,500 Square Feet
CLIENT: California Department of Corrections and Rehabilitation
DELIVERY METHOD: Design-Bid-Build (DBB)
ARCHITECT:
Perkins Eastman – Marina Del Rey, California
CGL Companies – Sacramento, California
SERVICES PROVIDED: Security Electronics System Design

DESCRIPTION: The California Medical Facility (CMF), an adult male prison with custody Level I, II and III inmates. The purpose of the health care facility improvement project at CMF is to remedy deficiencies in the health care components established by the California Correctional Health Care Services (CCHCS) program for Intermediate institutions. CMF has deficiencies in medication distribution, primary care, specialty care, health records, pharmacy, and health care administration. The Project includes six sub projects including the construction of new buildings, renovation of existing buildings, infrastructure, and ancillary improvements. The following sub projects are intended to remedy the above deficiencies for this campus:

  • Sub Project # 1- New Central Health Services Specialty Clinic
  • Sub Project # 2- New Stand-by Emergency Room (Licensed Building)
  • Sub Project # 4- Medication Distribution Room
  • Sub Project # 5- B-Wing Renovation
  • Sub Project # 6- X-Wing Renovation – Health Records
  • Sub Project # 7- Unit IV Renovation – Medication Distribution Rooms
  • Sub Project # 8- Infrastructure Upgrade

LEED Silver

DeWitt Nelson Conversion Annex

DeWitt Nelson Conversion Annex

DESCRIPTION: The DeWitt Nelson Complex Annex consists of 14 buildings originally built in 1967 to be used as a youth correctional facility. This project converts the usage to house a significant portion of the Specialized General Population (SGP) and the Enhanced Outpatient Program (EOP) of the state prison population; renovates and alters existing facilities for the re-purposed mission; adds new facilities including a new perimeter system with towers, a lethal fence, and vehicle sallyport; and provides for a common low voltage security electronic, fire alarm, IT/data, and maintenance management infrastructure as the adjacent California Health Care Facility, a mental and medical health prison.

The project includes developing bridging and criteria documents, plans, and system layout for California Department of Corrections and Rehabilitation (CDCR) to delineate technologies to be used in a new 1,133 bed medical and mental health prison on the existing Stockton prison campus. LEED Silver

LOCATION: Stockton, California
FACILITY SIZE: 255,000 Square Feet, 1,133 Beds
CLIENT: – California Department of Corrections and Rehabilitation
DELIVERY METHOD: – Design-Build (DB)
ARCHITECT:
Lee, Burkhart, Liu, Inc. – Marina Del Rey, California
CGL Companies – Sacramento, California
Kitchell CEM – Sacramento, California
SERVICES PROVIDED: Security Electronics System Design

Grande Ronde Hospital

Grande Ronde Hospital

DESCRIPTION: Grande Ronde Hospital is a not-for-profit, 25-bed Critical Access Hospital (CAH). In addition to the Hospital and its broad range of diagnostic, surgical and therapeutic outpatient services, the main facility also houses the Regional Hematology and Oncology Clinic, the Family Birthing Center, the Rehabilitation Therapy Department and Gym, and the Home Care Services Department which includes Home Health Services and Hospice Care. Grande Ronde Hospital is accredited by the Joint Commission and is a member of the American Small Hospital Association.

This project relocates the existing chiller plant to a centralized location, freeing up valuable space for the OR expansion. Additionally, this project cleans up various issues with the site primary distribution systems and provided a preliminary emergency power study to determine the feasibility of co-locating the emergency power generator plant with the chiller plant.

LOCATION: La Grande, Oregon
CLIENT: Grande Ronde Hospital
DELIVERY METHOD: Energy Services Performance Contracting (ESCP)
ENERGY SERVICES PERFORMANCE CONTRACTOR: Johnson Controls – Spokane, Washington
ARCHITECT: NAC|Architecture – Spokane, Washington
SERVICES PROVIDED: Electrical System Design

Benewah Community Hospital, Surgery and LDR Addition

Benewah Community Hospital, Surgery and LDR Addition

DESCRIPTION: This project included renovations and addition for a new surgical suite, new post-anesthesia care unit (PACU) space, and renovation of the existing surgery space to an LDR suite.

The electrical design included extensive modification to the main service electrical equipment and renovation of the emergency power system, including replacement and upsizing the existing emergency generator. The emergency power system renovation also included new NEC 517 emergency power branches for the new and renovated areas.

LOCATION: St. Maries, Idaho
CLIENT: Benewah Community Hospital
DELIVERY METHOD: Design-Bid-Build (DBB)
ARCHITECT: OMS Architects – Spokane, Washington
SERVICES PROVIDED: Electrical System Design

Mann-Grandstaff VA Medical Center, Endoscopy Addition

Mann-Grandstaff VA Medical Center, Endoscopy Addition

DESCRIPTION: This project includes additions of the Endoscopy and the Supply, Processing and Distribution (SPD) areas. Both additions are second floor additions to existing structures, and include renovations where intertied to the existing second floor structure.

The Endoscopy addition includes exam rooms, four (4) procedure rooms, pre and post-op bays, scope/equipment storage, clean and soiled utility rooms, waiting and reception areas.

The SPD addition includes lab offices, equipment storage, scope cleaning, cart washing, prep and sterilization rooms, prep/sterilization storage, decontamination rooms, sterilizers, a walk-in lab cooler, lab storage, and a service elevator.

LOCATION: Spokane, Washington
FACILITY SIZE: 20,100 Square Feet
CLIENT: U.S. Department of Veteran’s Affairs
DELIVERY METHOD: Design-Bid-Build (DBB)
ARCHITECT: NAC|Architecture – Spokane, Washington
SERVICES PROVIDED: Electrical System Design

Deaconess Medical Center Chiller Plant

Deaconess Medical Center Chiller Plant

DESCRIPTION: Electrical design consisted of support for the replacement of two chillers, associated chilled water pumps, variable frequency drives, and miscellaneous equipment. Electrical design included re-configuration of the chiller room switchboard and replacement of an existing motor control center. Due to phasing requirements, a temporary chiller was connected to the hospital electrical systems while the chiller plant was being replaced.

LOCATION: Spokane, Washington
CLIENT: Deaconess Medical Center
DELIVERY METHOD: ESCO
PRIME CONSULTANT: Johnson Controls – Spokane, Washington
SERVICES PROVIDED: Electrical Consulting

Lakeland Village Campus Emergency Power System Study

Lakeland Village Campus Emergency Power System Study

LOCATION: Medical Lake, Washington
CLIENT: Washington State, Department of Social and Health Services
DELIVERY METHOD: N/A
PRIME CONSULTANT: Apollo Solutions Group – Spokane, Washington
SERVICES PROVIDED: Electrical Consulting

DESCRIPTION: Lakeland Village is a state operated 24-hour facility with 52 buildings that provides all facets of training, education and health care for about 250 individuals with developmental disabilities. Lakeland Village is federally certified for 60 Nursing Facility (NF) beds and 190 Intermediate Care Facility/Mental Retardation (ICF/MR) beds.

The existing generator backed power system consists of a single emergency generator routed thru a step up transformer to feed a 15kV automatic transfer switch. The switch feeds a primary loop system with associated pad-mount transformers. Individual transformers are aggregated to serve multiple buildings and loads.

While this is one of the most efficient means of distributing generator backed power across the campus, unfortunately, it no longer meets current code, especially when buildings with different classifications are connected together. This study reviewed the existing campus generator backed power system, determined load calculations of the existing system and individual buildings, provided recommendations to bring each building up to current code, and provided budgeting for upgrades based upon the recommendations.

Multiple scenarios for replacement of the generation equipment were considered including utilization of distributed generation across the campus, utilization of a single generator, with different transfer switch configurations, and utilization of paralleling equipment with multiple generators for redundancy.

Lakeland Village Campus Chiller Replacement

Lakeland Village Campus Chiller Replacement

DESCRIPTION: Lakeland Village is a state operated 24-hour facility with 52 buildings that provides all facets of training, education and health care for about 250 individuals with developmental disabilities. Lakeland Village is federally certified for 60 Nursing Facility (NF) beds and 190 Intermediate Care Facility/Mental Retardation (ICF/MR) beds.

This energy-saving project involves replacing the two existing 225 ton campus chillers with two 300 ton units. Additionally outdated chilled water supply and return pumps were replaced along with the exterior cooling towers. Electrical work included replacement of the existing service entrance switchgear, modification of the existing motor control centers to include new VFD’s and harmonic filtering.

LOCATION: Medical Lake, Washington
CLIENT: Department of Social and Health Services
DELIVERY METHOD: ESCO
PRIME CONSULTANT: Apollo Solutions Group – Spokane, Washington
SERVICES PROVIDED: Electrical Consulting

LOCATION: Medical Lake, Washington

CLIENT: Department of Social and Health Services

DELIVERY METHOD: ESCO

PRIME CONSULTANT: Apollo Solutions Group Spokane, Washington

SERVICES PROVIDED: Electrical Consulting

DESCRIPTION:Lakeland Village is a state operated 24-hour facility with 52 buildings that provides all facets of training, education and health care for about 250 individuals with developmental disabilities. Lakeland Village is federally certified for 60 Nursing Facility (NF) beds and 190 Intermediate Care Facility/Mental Retardation (ICF/MR) beds.

This energy-saving project involves replacing the two existing 225 ton campus chillers with two 300 ton units. Additionally outdated chilled water supply and return pumps were replaced along with the exterior cooling towers. Electrical work included replacement of the existing service entrance switchgear, modification of the existing motor control centers to include new VFD’s and harmonic filtering.

Medical Lake Campus Master Plan

Medical Lake Campus Master Plan

DESCRIPTION: The master plan was designed to find ways to consolidate the utilities, services, and functions between three distinct but contiguous DSHS (Department of Social and Health Services) campuses comprised of Eastern State Hospital, Lakeland Village, and Pine Lodge Corrections Center. The master plan was in response to the need to address some of the failing infrastructure across the Medical Lake Campus, with the goal of reducing the capital costs associated with upgrading the failing infrastructure. The information and estimates provided in the master plan was used by DSHS to develop their ten year capital request for the Medical Lake Campus.

LOCATION: Medical Lake, Washington
FACILITY SIZE: 1,575,000 Square Feet
CLIENT: Washington State, Department of Social and Health Services (DSHS)
ARCHITECT: NAC|Architecture – Spokane, Washington
Deneff Deeble Barton Associates – Spokane, Washington
SERVICES PROVIDED: Electrical and Low Voltage System Planning

LOCATION: Medical Lake, Washington

FACILITY SIZE: 1,575,000 Square Feet

CLIENT: Washington State Department of Social and Health Services (DSHS)

ARCHITECT: NAC|Architecture Spokane, Washington

Deneff Deeble Barton Associates Spokane, Washington

SERVICES PROVIDED: Electrical and Low Voltage System Planning

DESCRIPTION: The master plan was designed to find ways to consolidate the utilities, services, and functions between three distinct but contiguous DSHS (Department of Social and Health Services) campuses comprised of Eastern State Hospital, Lakeland Village, and Pine Lodge Corrections Center. The master plan was in response to the need to address some of the failing infrastructure across the Medical Lake Campus, with the goal of reducing the capital costs associated with upgrading the failing infrastructure. The information and estimates provided in the master plan was used by DSHS to develop their ten year capital request for the Medical Lake Campus.

Clearwater Valley Medical Clinic

Clearwater Valley Medical Clinic

DESCRIPTION: The Clearwater Valley Medical Clinic provides a 20,000 square foot medical clinic separated from the Clearwater Valley Hospital to provide distinction between the two functions. The medical clinic consists of imaging, exam, office and physical therapy space and also provides classroom and conference rooms for local community events. The electrical design includes normal power, lighting, fire alarm, data/telephone, fire alarm and signaling systems.

Photos courtesy of NAC|Architecture.

LOCATION: Orofino, Idaho

FACILITY SIZE: 20,142 Square Feet
CLIENT: Clearwater Valley Hospital
DELIVERY METHOD: Design-Bid-Build (DBB)
ARCHITECT: NAC|Architecture – Spokane, Washington
CONTRACTOR: Walker Construction – Spokane, Washington
SERVICES PROVIDED: Electrical System Design

LOCATION: Orofino, Idaho

FACILITY SIZE: 20,142 Square Feet

CLIENT: Clearwater Valley Hospital

DELIVERY METHOD: Design-Bid-Build (DBB)

ARCHITECT: NAC|Architecture Spokane, Washington

CONTRACTOR: Walker Construction Spokane, Washington

SERVICES PROVIDED: Electrical System Design

DESCRIPTION: The Clearwater Valley Medical Clinic provides a 20,000 square foot medical clinic separated from the Clearwater Valley Hospital to provide distinction between the two functions. The medical clinic consists of imaging, exam, office and physical therapy space and also provides classroom and conference rooms for local community events. The electrical design includes normal power, lighting, fire alarm, data/telephone, fire alarm and signaling systems. This project currently is under construction. You can view the construction progress here.

Renderings courtesy of NAC|Architecture.

Lakeland Village Campus Nurse Call Replacement

Lakeland Village Campus Nurse Call Replacement

DESCRIPTION: :akeland Village is a state operated 24-hour facility that provides all facets of training, education and health care for about 250 individuals with developmental disabilities.

Lakeland Village is federally certified for 60 Nursing Facility (NF) beds and 190 Intermediate Care Facility/Mental Retardation (ICF/MR) beds.

This project included design of nurse call systems for the South Campus licensed facilities, along with central reporting of each building’s systems. Project design included modifications to the existing campus fiber optic network.

LOCATION: Medical Lake, Washington
FACILITY SIZE: 12 Campus Buildings
CLIENT: Washington State DSHS
DELIVERY METHOD: Design-Bid-Build
ARCHITECT: DeNeff Deeble Barton Associates – Spokane, Washington
SERVICES PROVIDED: Electrical and Electronics System Design

Eastern State Hospital, FSU Security System Improvements

Eastern State Hospital, FSU Security System Improvements

DESCRIPTION: This project started as a study to provide options for the replacement of the existing low voltage security electronics systems within the Forensic Services Unit of the Eastlake Building. The study and report identified current available technologies, and provided a cost implementation plan to develop the project for funding in the next biennium State funding cycle.

After funding was secured, design documents were prepared, and construction administration services provided for remodeling of the existing systems to provide new low voltage security electronics systems, including the following:

  • Door control systems.
  • CCTV systems.
  • Intercom and Paging systems.
  • Access control systems.
  • Network infrastructure.
  • UPS Systems.

LOCATION: Medical Lake, Washington
FACILITY SIZE: 76,700 Square Feet, 105 Beds
CLIENT: Washington State DSHS
DELIVERY METHOD: Design-Bid-Build
ARCHITECT: NAC|Architecture – Spokane, Washington
SECURITY ELECTRONICS CONTRACTOR: Engineered Control Systems/Cornerstone Detention – Spokane, Washington
SERVICES PROVIDED: Electrical and Security Electronics System Design

Eastern State Hospital, Westlake Building

Eastern State Hospital, Westlake Building

LOCATION: Medical Lake, Washington
FACILITY SIZE: 145,000 Square Feet
CLIENT: Washington State, Department of Social and Health Services
DELIVERY METHOD: Design-Build (DB) and Design-Bid-Build (DBB)
ARCHITECT: DeNeff Deeble Barton Associates – Spokane, Washington
CONTRACTOR: Power City Electric – Spokane, Washington
SERVICES PROVIDED: Electrical System and Electronics Design

DESCRIPTION: Design of multiple projects for the Eastern State Hospital campus, with multiple projects within the Westlake Building. The major projects for the Westlake Building include:

  • Fire Alarm and Nurse Call Systems Replacement.
  • Generator Replacement.
  • Building Lighting Upgrades.

The Fire Alarm and Nurse Call Replacement project included the removal and replacement of both the fire alarm and nurse call systems within the existing secure psychiatric hospital. Elevator recall and electrical systems where modified to provide necessary code required interfaces to the fire alarm system. This project also included revising the network of the existing fire alarm control system on the Eastern State Hospital campus so that the new fire alarm system could connect to the campus network.

The Generator Replacement project removed and replaced the existing 25 year old 500kW diesel fueled generator.

The Building Lighting Upgrade project included the replacement of both the existing lighting systems in all five (5) patient wards and selected areas within the remainder of the rest of the psychiatric hospital. Moreover, patient room lighting systems were upgraded to include overbed fixtures for nighttime use; ward dayroom lighting controls were added for energy efficiency; and occupancy sensors were added to office and conference rooms.

Providence Holy Family Hospital, Surgery and Oncology Addition

Providence Holy Family Hospital, Surgery and Oncology Addition

DESCRIPTION: This project included a 42,000 square foot expansion of the surgery suites, new pre-operative and phase 2 post-operative facilities, and a remodel of the Oncology Department.  In addition, a new 4 story, 66,000 square foot medical office building was interconnected to the Oncology Expansion.

Electrical design included extension of existing normal and emergency power systems, extension of the existing fire alarm and nurse call systems, lighting, grounding, and provisions for future data/telephone, security, and CATV systems.

Modifications were made to the existing central plant equipment including addition of a new chiller and supporting equipment (cooling tower, VFD’s, chilled water pumps, and machine room emergency ventilation equipment); and modifications to the existing hot water heating systems including addition new pumping equipment and VFD’s.

Special design challenges included designing the Holy Family Catheterization Lab upgrade which utilized the same systems as the Surgery and Oncology Expansion as well as maintaining continuity of operations for the Catheterization Lab during the upgrade.

LOCATION: Spokane, Washington
FACILITY SIZE: 108,000 Square Feet
CLIENT: Providence Holy Family Hospital
DELIVERY METHOD: Design-Bid-Build (DBB)
CONTRACTOR: Bouten Construction – Spokane, Washington
ARCHITECT: NAC|Architecture
SERVICES PROVIDED: Electrical and Electronic System Design

California Health Care Facility

California Health Care Facility

DESCRIPTION: The California Health Care Facility Stockton is an intermediate-level medical and mental health care facility for inmate-patients within the California State prison system. This new facility is comprised of inmate-patient housing (1,722 Beds), diagnostic and treatment centers, a central utility plant, central kitchen, materials service center, and facility support areas to total 1.2 Million GSF.
The project includes developing bridging and criteria documents, work plans, and system layout for California Department of Corrections and Rehabilitation (CDCR) to delineate technologies to be used in a new 1,722 bed medical and mental health prison on the existing Stockton prison campus. LEED Silver.

LOCATION: Stockton, California
FACILITY SIZE:
Bid Pack #1: 112,000 Square Feet
Bid Pack #2: 1,200,000 Square Feet
144 Acre Campus
1,722 Beds
CLIENT: California Department of Corrections and Rehabilitation
DELIVERY METHOD: Design-Build (DB)
ARCHITECT:
Lee, Burkhart, Liu, Inc. – Marina Del Rey, California
CGL Companies – Sacramento, California
Kitchell CEM – Sacramento, California
SECURITY ELECTRONICS CONTRACTOR: Metroplex Control Systems/ISI Security – San Antonio, Texas
SERVICES PROVIDED: Security Electronics System Design
